Duo Power Xi 8000 smart

The AKO Duo Power Xi 8000 smart combines maximum power with smart technology.

With 12 Joules of charging energy, cloud connection, free mobile data transfer and a flexible 12/230 V power supply, it offers maximum power for your pasture up to a length of 50 km - at all times and in all places!

  • extremely powerful 12/230 Volt DUO fence device for mobile or stationary use
  • can be used even with heavy vegetation
  • our all-round device – ideal for horses, bulls, sheep and for deterring wild boars and wolves
  • directly integrated cloud connection
  • distance-neutral control (ON/OFF, GPS tracking) and monitoring of fence systems by smartphone
  • permanently free mobile data transfer to the app
  • with High/Low/OFF switch for 2 different output powers
  • 5-year warranty

multi-colour LED bar graph display for output voltage and battery control

recommended solar module: 375999 (100 W), connection directly to the 12-Volt battery, optionally with ground anchor 442386 or fixing set 442386 for metal box

Items
Ref. no.PUPallet
372879172 PAL

Impact force and fence length: the AKO Duo Power Xi 8000 smart is equipped with a charging energy of 12 J and a maximum voltage of 11,200 V. The device is used for fence systems up to 50 km without vegetation.

Power supply and animals: the device is a 12/ 230 V DUO fence device that can be operated with a 12 V connection cable or a 230 V mains adapter. Ideal for horses, cattle, sheep, wild boar and wolves.

Functions: The Smart Energiser has an integrated connection to the cloud. This function enables distance-independent control and monitoring of the fence system via smartphone. The device is equipped with an I=ON-Low|0=OFF|II=ON-High switch.

Display: the device is equipped with a multi-coloured LED bar graph display (11 LEDs). The lower "red" LED indicates the battery check. The 10 LEDs above (red/yellow/green) are used for visual monitoring of the output voltage. Red =< 2,000 V | Yellow/green => 2,000 V.

Housing and assembly: the robust housing made from UV-resistant plastic is weather-resistant and long-lasting. An integrated fitting allows wall mounting. If installed outdoors, the device must also be protected from rain and sunshine.

  • 12/230 Volt DUO Unit – maximum flexibility combined with powerful output
  • multi-colour, illuminated bar graph display (10 LEDs) for monitoring the output voltage
  • separate LED for battery warning (red)
  • optimised consumption thanks to energy saving mode – saves battery power in fences in good condition. Also intelligent battery management for when battery voltage decreases.
  • deep discharge protection for the 12 volt battery
  • microprocessor controlled
  • solar backup possible
  • robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
  • integrated hanging device for wall mounting
  • corresponds to applicable EU safety standards
  • (suitable for metal box 44656 and 44650)
  • AKO Xi device automatically adapts to the fence status, ensures highest protection certainty, and makes your work easier by reducing vegetation growth to a certain degree
  • the fence is constantly monitored by an alarm function, which triggers an alarm and slows the pulse sequence if the fence is touched for an extended period of time
  • delayed shock strength adjustment makes touching the fence safer for people and animals

ModelRef. no.Stored Energymax. discharge energymax. voltageVoltage in Open CircuitVoltage at 500 Ohmstheoretical fence length as per VDEmax. fence length without vegetationmax. fence length with medium vegetationmax. fence length with high vegetationApprox. Number of Electrifiable NetsQty 1 m earth postsQty 2 m earth posts
Xi 8000 smart37287912 J8 J11200 V10200 V8700 V240 km50 km17 km7 km3063

  • 1 x fence unit
  • 1 x 230 volt power pack (371030)
  • 1 x 12 Volt connection cable (E268739)
  • 1 x fence / ground connector cable
  • 1 x warning sign
