Drinking Bowls K50

The Kerbl K50 drinking bowl, made from high-quality plastic, is suitable for cattle and horses. It features a 4-hole fastening system, wall and tube mounting options, as well as G 1/2‘ and G 3/4’ connections.

  • water bowl made from high-quality plastic
  • lockable tongue (separate accessory)
  • 4-hole fastening
  • suitable for 1/2" and 3/4" connections
  • fastening material not included
  • for wall and pipe mounting

suitable for 1/2" and 3/4" connections

Items
Ref. no.DescriptionColourWater ConnectionCapacityMOQPieces / unitPUPallet
225031Kerbl designgreenG 1/2" / G 3/4"2.2 L1120 PAL
225032Kerbl designolive greenG 1/2" / G 3/4"2.2 L1120 PAL
225030neutral presentationblueG 1/2" / G 3/4"2.2 L1120 PAL
225033neutral presentationblackG 1/2" / G 3/4"2.2 L2 pieces2 / box1/2160 PAL
Accessories
Ref. no.DescriptionColourMaterialConnectionFrame HeightPU
221971Guard Size 2 hot-dip galvanised metal 20 cm1/4
223426Valve high-pressure Brass  1/20/200
22501Tube Mounting Bracket with Stabilising Plates in pairs Metal  1/25
2250341Panel Lock for Drinking Trough K50    1/50/500
225034Nose PaddleblackPlastic  1/40
2218606Sealing PlugblackPlasticG 3/4" 1/200


Robust plastic: the Kerbl K50 drinking trough is made of high-grade plastic and is a hard-wearing drinking solution for stables and outlets. It has a capacity of 2.2 l.

Flexible installation: the 4-hole fastening system allows for stable wall or tube mounting. Fixing materials are not included in the scope of delivery and can be selected as required.

Compatible connections: the drinking bowls are suitable for G 1/2‘ and G 3/4’ connections. The water connection can be flexibly fitted from either the top or the bottom.

Adjustable flow rate: the water flow rate is adjustable to three settings. The flow rate is 7.5 min. or 11 min. at 3 bar, ensuring a reliable water supply.

Controlled use: the drinking bowl’s tongue can be locked shut if required using a paddle lock (available separately). This enables precise control of water usage in the barn.

Technical DataDimensions (W x D x H)Connection optionWater Flow RateFlow rateWeight
22503121 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503221 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503021 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503321 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g

Preview imageItem. No.Description225031225032225030225033
High-pressure valve replacem.223426High-pressure valve replacem.xxxx
Valve cone brass,223427Valve cone brass,xxxx
Spare Tongue Plstic Drnkng Bwl225034Spare Tongue Plstic Drnkng Bwlxxxx
Sealing Plugs plastic 3/42218606Sealing Plugs plastic 3/4''xxxx
 225029Axle with Nuts for 225030,xxxx
